◀◀ Key Selling Points ▶▶
1.Industrial-grade durability
With an IP67 protection rating, it is waterproof and dustproof, suitable for extreme outdoor environments.
It is equipped with a built-in supercapacitor and can continue to work for 1 minute after power failure to send an alarm.
2.High-performance hardware
A 64-bit quad-core processor (5GHz) paired with 512MB DDR4 RAM, supporting high-speed data processing.
The new generation SX1302 LoRa® chip enhances signal reception sensitivity and coverage.
3.Large-scale equipment connection
Supports over 2000 terminal nodes and can simultaneously receive data from 8 terminal devices.
Dual external LoRa® antennas + built-in cellular /Wi-Fi antennas to enhance signal coverage.
4.Flexible connection and compatibility
Multiple backhaul methods: Ethernet, Cellular network (4G), Wi-Fi.
Compatible with mainstream network servers (such as Actility, AWS, ChirpStack, etc.), and supporting BACnet/Modbus protocol integration with building management systems (BMS).
5.Intelligent management and deployment
Plug and Play: Automatically configure through RPS services and remotely manage gateway fleets.
Integrate Node-RED to quickly realize the automated workflow of devices and apis.
The BGT Hydromet development platform offers templated configuration and remote monitoring.
6.Ease of installation
It provides installation plates and supports various installation methods such as pole mounting and wall mounting.
Spectrum scanning function, optimizing deployment location.
◀◀ Product Parameters ▶▶
| Category | Details |
|---|---|
| Hardware | - Processor: 64-bit quad-core (5GHz) - Memory: 512MB DDR4 RAM - Chip: SX1302 LoRa® chip - Power supply: Built-in supercapacitor (power off for 1 minute) |
| Network | - Maximum points: 2000+ - Concurrent reception: 8 terminal devices - Return transmission methods: Ethernet, 4G cellular, Wi-Fi - Frequency band: Supports global LoRaWAN® frequency bands (EU868/US915, etc.) |
| Antenna configuration | - Built-in: Cellular /Wi-Fi antenna - External: Dual LoRa® antennas (expandable Protection and Durability - Protection grade: IP67 - Operating temperature: Adaptable to -40°C to 75°C |
Software Functions | - Compatible with network servers: Actility, AWS, ChirpStack, etc - Protocol support: BACnet, Modbus |
| Installation and Expansion | - Installation methods: Pole mounting, wall mounting - Extended Function: Gateway Fleet (Centralized management of multiple gateways) - Tool support: Spectrum scanning optimized deployment |
◀◀ Application Scenarios ▶▶
Smart Cities: Connect streetlights, waste management sensors, air quality monitors, and parking systems across urban areas.
Agriculture: Monitor soil moisture, weather stations, and livestock tracking in remote farms.
Industrial IoT: Enable predictive maintenance for machinery, tank level monitoring, and warehouse asset tracking.
Environmental Monitoring: Deploy in forests, mountains, or coastal regions for wildfire detection, flood alerts, or wildlife conservation.
Utilities: Manage smart meters (water/gas/electricity) in decentralized locations with low-power, long-range connectivity.
Emergency Services: Provide reliable communication for disaster recovery operations in areas with limited cellular coverage.
