◀◀ Key Selling Points ▶▶
Full Automation
Auto-replaces microscope slides (360-slide capacity) and uploads data via 4G/WiFi, enabling months of unmanned operation.
AI-Driven Precision
1,200x magnification + adaptive focusing captures ultra-clear spore images (±1μm accuracy).
Cloud-based AI identifies species and quantifies spore density.
Robust Design
IP25-rated housing withstands harsh weather (-20°C–60°C, ≤95% humidity).
Solar-powered (optional 400W panel) for off-grid deployments.
Real-Time Monitoring
Integrates GPS, rain/light sensors, and air quality detectors for holistic environmental analysis.
Eco-Friendly & Efficient
Reduces chemical pesticide use by 50% through early pathogen detection.
◀◀ Product Parameters ▶▶
| Category | Details |
|---|---|
| Microscope | 1,200x magnification; auto-focusing (±0.5μm) |
| Slide Capacity | 360 slides (76.2×25.4×1-1.2mm) |
| Airflow | 0.3–5 m/s adjustable suction |
| Power Supply | 220V AC or 400W solar panel |
| Data Transmission | 4G/Cloud; GPS tracking for anti-theft |
| Sensors | Rain/light/air temp & humidity sensors |
| Material | Galvanized spray-coated steel (anti-corrosion) |
| Dimensions | Compact design for field deployment |
◀◀ Application Scenarios ▶▶
Large-Scale Farms
To prevent crop loss, monitor crop diseases (e.g. wheat rust and riceblast).
Forestry & Nurseries
Detect invasive pathogens in tree plantations (e.g. Phytophthora).
Ecological Research
Track patterns of spore dispersal in biodiversity reserves.
Remote Areas
Solar-powered operation provides 24/7 monitoring for off-grid areas.
Academic Labs
High-resolution imaging allows you to study spore evolution, resistance mechanisms and spore growth.
