◀◀ Key Selling Points ▶▶
Ultra-wide measurement range (±1500 με) for large-scale strain monitoring.
Dual functionality: Combines strain sensing and temperature measurement (FBG-T) for data accuracy.
Versatile installation: Supports welding, mechanical fixtures, or adhesive bonding.
High resolution (0.1% FS) and low nonlinearity (≤1.0% FS) for reliable static/dynamic monitoring.
Robust performance in harsh conditions (-30°C to +80°C).
Compact design (162mm × φ18mm) for minimal intrusion on structures.
◀◀ Product Parameters ▶▶
| Parameter | Details |
|---|---|
| Standard Range | ±1500 με |
| Nonlinearity | ≤1.0% FS |
| Resolution | 0.1% FS |
| Gauge Length | 150 mm |
| Operating Temperature | -30°C to +80°C |
| Dimensions | 162mm × φ18mm (excluding mounting blocks) |
| Installation Methods | Welding, mechanical fixtures, adhesive |
| Special Feature | Integrated temperature-sensing FBG ("T") |
◀◀ Application Scenarios ▶▶
Civil infrastructure: Monitor bridges, pipelines, or steel frameworks for stress anomalies.
Industrial machinery: Track dynamic strain in rotating equipment or heavy machinery.
Aerospace/automotive: Test structural integrity under extreme loads or temperature fluctuations.
Energy systems: Assess strain in wind turbine blades, nuclear facilities, or oil/gas pipelines.
Temporary/permanent installations: Ideal for field testing or long-term structural health monitoring.
Temperature-sensitive environments: Applications requiring simultaneous strain and temperature data.
