◀◀ Key Selling Points ▶▶
✅ Multi-Sensor Precision
3–6 high-accuracy vibrating wire sensors for real-time total load monitoring.
Detects uneven/off-center loads via individual sensor analysis.
✅ Extreme Environment Ready
Operates in -40°C to +65°C with IP68-rated waterproofing.
Optional 0.5–2MPa hydrostatic pressure resistance (customizable).
✅ Robust & Customizable
Overload capacity: 25%+ (extendable on request).
Flexible sensor count (3–6) and load ranges (250–3000+ kN) for diverse projects.
✅ Smart Temperature Compensation
Built-in temperature sensor eliminates thermal drift errors.
◀◀ Product Parameters ▶▶
| Parameter | Specification |
|---|---|
| Standard Range | 300–900 kN |
| Non-linearity | ≤2% FS (linear) ≤1% FS (polynomial) |
| Resolution | 0.03% FS |
| Operating Temp. | -40°C to +65°C |
| Overload Capacity | 25% (default) Customizable |
| Sensor Count | 3 |
| Dimensions | Height: 45mm Inner/Outer Diameter: Customizable |
◀◀ Application Scenarios ▶▶
Shield Tunnel Engineering
Monitor preload stress in tunnel segment bolts to ensure structural integrity during excavation.
Steel Structure Assembly
Accurately measure bolt tension in bridges, high-rises, and industrial frameworks.
Post-Tensioned Anchors
Track long-term stress stability in bridge cables or slope reinforcement systems.
Heavy Machinery Maintenance
Prevent bolt loosening or fatigue failure in equipment under dynamic loads.
