◀◀ Key Selling Points ▶▶
✅ Multi-Sensor Precision
3–6 high-accuracy vibrating wire sensors for real-time total load monitoring.
Detects uneven/off-center loads via individual sensor analysis.
✅ Extreme Environment Ready
Operates in -40°C to +65°C with IP68-rated waterproofing.
Optional 0.5–2MPa hydrostatic pressure resistance (customizable).
✅ Robust & Customizable
Overload capacity: 25%+ (extendable on request).
Flexible sensor count (3–6) and load ranges (250–3000+ kN) for diverse projects.
✅ Smart Temperature Compensation
Built-in temperature sensor eliminates thermal drift errors.
◀◀ Product Parameters ▶▶
| Parameter | BGT4900 Range 1 | BGT4900 Range 2 | BGT4900 Range 3 |
|---|---|---|---|
| Standard Load Range | 250–999 kN | 1000–2999 kN | >3000 kN |
| Non-linearity | ≤1% FS (linear) ≤0.5% FS (polynomial) | Same | Same |
| Resolution | 0.05% FS | 0.05% FS | 0.05% FS |
| Operating Temp. | -40°C to +65°C | -40°C to +65°C | -40°C to +65°C |
| Sensor Count | 3 | 3–4 | 4–6 |
| Overload Capacity | 25% (default) Customizable | Same | Same |
| Water Pressure | Customizable (0.5/2MPa or higher) |
◀◀ Application Scenarios ▶▶
Mining & Tunnel Engineering
Monitor anchor cable loads in underground mines or tunnel arch supports to prevent structural failure.
Slope Stabilization
Track rock bolt tension in landslide-prone areas for early risk detection.
Bridge & Dam Safety
Ensure long-term stability of suspension cables and anchoring systems in critical infrastructure.
Offshore Platforms
Withstand corrosive marine environments while measuring mooring line loads.
