◀◀ Key Selling Points ▶▶
High accuracy & sensitivity for precise stress measurement.
Waterproof design with customizable pressure resistance (up to 3 MPa).
Built-in temperature sensor for environmental monitoring.
Cable length-independent signals for stable performance in extreme conditions.
Flexible installation: Welding or threaded connectors (customizable sizes).
Multiple diameter options (12–40 mm) to match varied rebar specifications.
Long-term reliability with minimal drift over time.
◀◀ Product Parameters ▶▶
| Parameter | Details |
|---|---|
| Standard Range | 300 MPa / 400 MPa |
| Nonlinearity | ≤1% FS (linear) / ≤0.5% FS (polynomial) |
| Resolution | 0.05% FS |
| Temperature Range | -20°C to +80°C |
| Water Pressure | Customizable (e.g., 2 MPa, 3 MPa) |
| Diameter Options | 12–40 mm (300 MPa); 16–40 mm (400 MPa) |
| Connection Rod | High-strength threaded steel |
| Optional Accessories | BGT02-250V6 shielded cable, BGT408VR readout unit, threaded connectors |
◀◀ Application Scenarios ▶▶
Concrete structures: Monitor rebar stress in buildings, bridges, dams, etc.
Anchor rod systems: Track stress in tunnels, slopes, or underground supports.
Harsh environments: Long-term monitoring in high humidity, extreme temperatures, or corrosive conditions.
Temperature-sensitive projects: Applications requiring temperature compensation for stress data.
Custom installations: Projects with specific threading or diameter requirements.
