Automatic Heating Professional Laser Snow Depth Multi-point Monitoring

This laser snow depth sensor uses the laser phase method to measure the snow depth. Laser Multi-Point Snow Depth Monitor, an advanced and dynamic snow monitoring solution designed specifically for photovoltaic (PV) power stations. Unlike traditional single-point sensors, our innovative device utilizes a 360° multi-point scanning system to deliver highly accurate and real-time snow depth measurements across solar panels of varying tilt angles. Equipped with intelligent temperature control, cloud-based data storage, and wireless connectivity, this monitor ensures reliable performance even in extreme cold, making it the most precise and efficient snow monitoring tool for PV plants and beyond.

Availability:

Quantity:



Inquire

◀◀ Key Selling Points ▶▶

✅ High-Precision Dynamic Measurement

360° multi-point scanning captures snow depth distribution across uneven surfaces, eliminating inaccuracies of static single-point sensors.
Real-time data feedback reflects actual snow accumulation on panels with different tilt angles.

✅ All-Weather Reliability

Built-in auto-heating system activates in extreme cold to maintain measurement accuracy and stability.
IP65+ grade ensures durability in harsh environments.

✅ Smart Data Management

Local + cloud storage: Data is saved locally and can be uploaded via 4G/WiFi/Bluetooth to our Lichen Smart Cloud Platform for remote monitoring.
Auto-watch mode enables continuous tracking and historical data review.

✅ Easy Deployment & Maintenance

Wireless configuration via Bluetooth for hassle-free parameter adjustments.
Low-power design with optional solar power support for off-grid applications.

You are here: Home / Products / Meteorological Monitoring / Temp. Humi. Pressure Sensors / Automatic Heating Professional Laser Snow Depth Multi-point Monitoring

Rotation angle	Horizontal 0~360°, vertical -85~20°
Rotation speed	Horizontal 0~9°/s, vertical 0~5°/s
Communication method	RS485/Bluetooth
Communication protocol	Standard Modbus protocol
Resolution	1mm
Measurement accuracy	Remove 1mm
Measurement range	0-50m
Measurement time	0.3-2 seconds
Measurement method	Laser phase method
Protection level	IP65
Number of automatic monitoring points	Up to 180
System time calibration	RTC memory time, can be adjusted at any time.
Power supply method	DC12-23V
Power consumption	Standby less than 2W
