◀◀ Key Selling Points ▶▶
◆◆ Advanced Radar Technology:
Utilizes 24GHz Doppler radar to measure the speed and size of raindrops, providing highly accurate precipitation data.
Capable of distinguishing between different types of precipitation (rain, snow, hail) based on the speed of falling droplets.
◆◆ High Accuracy and Resolution:
Offers a resolution of 0.1mm and an accuracy of ±10% for liquid precipitation, ensuring reliable and precise measurements.
2Long-term calibration with tipping bucket rain gauges in natural conditions guarantees consistent performance.
◆◆ Maintenance-Free Operation:
No need for heating devices to prevent freezing or worry about obstructions like leaves affecting the sensor's performance.
Designed for long-term use without the need for frequent maintenance.
◆◆ Robust and Durable Design:
Constructed with ASA material and rated at IP65 protection level, the sensor is resistant to harsh weather conditions, including extreme temperatures (-40℃ to +70℃) and high humidity (0-100%).
Compact and lightweight design (Ø105 * 192mm, 0.45kg) makes it easy to install and integrate into various systems.
◆◆ Versatile Communication Options:
Supports multiple communication interfaces, including RS485 and RS232, and protocols like ModBus, NMEA-0183, and ASCII, ensuring compatibility with a wide range of systems.
◆◆ Low Power Consumption:
Operates on a low voltage range of DC12-30V with a current consumption of 120mA@12V, making it energy-efficient and cost-effective.
◀◀ Product Parameters ▶▶
Model | BGT-RS2 |
Type of precipitation | Rain,Snow,Hail |
Measurement Range | 0.01-200mm/hour (liquid) precipitation) |
Accuracy | ±10% of the measured value for liquid precipitation |
Measuring drop size range | 0.5-5.0mm |
Resolution | 0.1mm |
Sample rate | 1 time per second |
Communication interface | RS485、RS232 |
Protocol | ModBus、NMEA-0183、ASCII |
Voltage | DC12-30V; 120mA@12V |
Operating Temperature | -40℃ － +70℃ |
Operating Humidity | 0-100% |
Size | Ø105 * 192mm |
Material | ASA |
Weight | 0.45kg |
Protection Grade | IP65 |
◀◀ Application Scenarios ▶▶
1. Weather Stations:
Ideal for meteorological monitoring, providing accurate and real-time precipitation data for weather forecasting and climate research.
2. Smart City Weather Systems:
Integrate into smart city infrastructure to monitor urban weather conditions, enabling better decision-making for traffic management, public safety, and emergency response.
3. River Flood Control and Forecasting:
Essential for flood forecasting systems, providing early warnings by monitoring rainfall intensity and patterns in real-time.
4. Agricultural Monitoring:
Used in precision agriculture to monitor precipitation levels, helping farmers optimize irrigation and crop management.
5. Aviation and Transportation:
Deployed at airports and along transportation routes to monitor weather conditions, ensuring safe operations during adverse weather.
6. Hydrological Research:
Suitable for hydrological studies, providing accurate precipitation data for water resource management and environmental monitoring.
The BGT-RS2 Radar Precipitation Sensor is the ultimate solution for accurate, reliable, and maintenance-free precipitation monitoring. Whether you're managing a weather station, a smart city, or a flood forecasting system, the BGT-RS2 delivers the performance you need.
