HY-VTF306BE: Precision Visibility Detection for Safer Roads, Skies, And Sites

BGT-VTF306BE: Precision Visibility Detection for Safer Roads, Skies, And Sites

In environments where visibility dictates safety, the BGT-VTF306BE Visibility Detector delivers unmatched reliability. Engineered with forward scattering technology, it measures atmospheric clarity from 10m to 100km, even in extreme conditions. Its rugged, IP65-rated aluminum housing and built-in heating ensure 24/7 performance through fog, snow, or dust storms.

Perfect for traffic management systems, airports, and industrial zones, this low-maintenance sensor simplifies installation and slashes operational costs. Trust BGT-VTF306BE to safeguard lives and operations—wherever clarity matters.

Availability:



Inquire

visibility meter how does a visibility meter work what does a visibility meter measure visibility meter buy what is a visibility meter used for

Key Selling Points

Product Parameters

Application Scenarios

◀◀ Key Selling Points ▶▶

· Wide Measurement Range

Default range of 10m to 10km, extendable up to 100km (customizable).
Optional rain accumulation measurement (0–500mm range, ±10% accuracy).

· Superior Accuracy & Reliability

Forward scattering technology (39°–51° angle) ensures precise visibility data.
Immune to interference from local light sources (e.g., streetlights, vehicle headlights).

· Robust Design & Durability

IP65-rated housing made of powder-coated hard-anodized aluminum.
Built-in hood heating for extreme environments (-40°C to +60°C).
Contamination compensation for reduced maintenance.

·Ease of Use

Simple installation (one-person setup) and low maintenance.
Compact, lightweight design (3.2 kg).

· Long-Term Value

10+ year lifespan with minimal upkeep.
Compatible with ModBus/ASCII protocols (RS232/RS485 outputs).

◀◀ Product Parameters ▶▶

Visibility measurement
Measures Range	10m to 10km (20km,30km,50km,80km,100km customizable at extra cost)
Accuracy	±10%
Measurement principle	Forward scattering measurement with 39° to 51° angle
Rain accumulation measurement(optional at extra cost)
Measures Range	0~500mm
Accuracy	±10%
Measurement principle	Optical
Output
Serial outputs	RS232 or RS485	Baud Rate	9600 bps
Protocol	ModBus or active output in ASCII
Environmental & Power Requirements
Operating temperature	-40°C to +60°C	Power consumption	12-24 VDC@3.8W
Operating humidity	0 – 100% RH	Protection rating	IP65
Physical
Material	Powder coated Hard-Anodized aluminium
Weight & Dimension	3.2 Kg; 706x250x170mm	Designed Lifetime	>10 Years
