You've probably heard of a Pyranometer, a device which measures solar irradiance, the power of sunlight striking a surface. Here's the question: does "Class B" matter when choosing a new pyranometer? The short answer is absolutely. The accuracy grades such as Class B directly affect the reliability of your data. In fields that require precise solar measurements to drive decisions (think about solar farm investments and climate studies), this reliability is non-negotiable.
This guide will explain what class B pyranometers do, how they are defined by international standards and where they excel (and may fall short) and how you can choose between Class B and Class A based on your specific needs. Let's get started.
Let's first clarify that pyranometers are classified according to their accuracy. ISO 9060 : 2018 is the most widely accepted standard for this grading. (Solar Energy -- Calibration Field Pyranometers) This standard categorizes instruments in three classes: Class A, Class B and Class C.
What makes a pyranometer a "Class B" pyranometer? We'll look at some of the ISO 9060:2018 requirements:
Response time: The speed at which the sensor responds to changes in light. Class B instruments are required to respond within 6 seconds to 95% of an abrupt irradiance shift (Class A only requires 3 seconds).
Temperature coefficient: Measures how much sensor readings vary with temperature. This drift is =0.05% for Class B (Class A has a stricter standard of =0.03%).
Non Stability: Maximum allowable change in calibrating over a period of 12 months. Class B allows a drift of up to 2% (Class A is limited to 1%).
Simpler: Class B instruments are good enough for everyday use, but they are less precise than Class A instruments. These are used for research with high stakes (e.g. climate modeling).
Compare Class A and Class B pyranometers to understand why grade matters:
| Parameter | Class B | Class A |
|---|---|---|
| Response Time | =3 second for 95% adjustment | =6 second for 95% adjustment |
| Temperature Coefficient | <=0.03% per degC | <=0.05% per degC |
| Non-Stability (12 mo.) | <=1% | <=2% |
These gaps are not only subtle, but also critical. A Class A pyranometer, for example, might be worth it if you are monitoring solar panels in the desert where temperatures fluctuate wildly. Its lower temperature coefficient will ensure that readings remain accurate, even on scorching hot days. In a region where the weather is stable, a Class A instrument should suffice.
They're useful. Here are three scenarios in which they make sense:
Daily irradiance is used to optimize solar farms, rooftops, and utility scale projects. You can, for example:
Solar farm managers might use Class B pyranometers to monitor daily energy output in relation to predicted irradiance. While Class A provides pinpoint accuracy, the 2% annual drift of Class B is negligible when making short-term decisions.
The cost is also a factor: Class B sensors can be 30-50% less expensive than Class A sensors, which makes them an affordable choice for large-scale deployments that require dozens of sensors.
Not all weather stations need Class A precision. A Class B pyranometer is suitable for climates with moderate temperature changes (e.g. subtropical and temperate zones).
Analysis of long-term climate trends
Crop yield forecasts (agricultural weather).
Urban Heat Island Studies
These applications place greater emphasis on consistency than microsecond-level response.
Students, hobbyists or researchers who are launching small-scale experiments in solar energy can benefit from Class B pyranometers. They offer an affordable and functional solution. You can, for example:
An university lab that is studying the efficiency of solar panels in a community can collect baseline data using a Class B device without spending a fortune.
Solar measurement principles can be demonstrated in science fairs and classroom projects without the need for Class A precision.
The technology of the sensor inside a Pyranometer is directly related to its grade. The majority of Class B instruments are equipped with thin film thermopile sensors, a cost-effective and durable design that converts solar energy into an electrical signal using the Seebeck Effect (where temperature differences between two metals produce voltage).
Why thin-film thermopiles?
These are robust: They resist humidity, dust and corrosion. This makes them perfect for outdoor use.
The cost is affordable: Because they are mass-produced and sold on commercial markets, the price of Class B Pyranometers has been reduced.
The temperature coefficients and response time are in line with ISO 9060:2018 for mid-range accuracy.
Thin-film thermopiles are not without limitations. They may not be as good at:
Accuracy in low-light: Dim lighting conditions (e.g. early morning, cloudy days or dark skies) can cause more noise.
Spectral Sensitivity: They might not capture the entire solar spectrum (300-2800nm) as equally as premium sensors.
Should you buy a Class B car or spend more on a Class A? Here's a quick decision tree:
Choose class B if
You work in a stable climate (no extreme temperature fluctuations).
Your application is based on cost-effectiveness (e.g. large-scale solar farm, regional weather station).
You are a student, an educator or a small researcher.
Select Class A if
You need a calibration drift of less than 1% per year (e.g. long-term climate studies).
Monitor extreme environments such as deserts and polar regions.
For R&D, high precision is essential (e.g. validating solar panel claims of efficiency).
Class B pyranometers are the unsung heroes of solar and meteorological measurement--reliable, practical, and tailored to everyday needs. Understanding their ISO standards and application boundaries as well as sensor technology will help you make a choice that balances cost, accuracy and performance.
A Class B Pyranometer is the perfect tool for anyone who manages a solar farm, or teaches a science course. It will provide you with all of the information you need without any unnecessary extras. In the world of solar measurements, accuracy can be valuable, but functionality can be priceless.
